Description
Specifications
| Model | GS-24 |
| Driving method | Digital control servo motor |
| Cutting method | Media-moving method |
| Loadable material width | 2 to 27-1/2 in. (50 to 700 mm) |
| Maximum cutting area | Width: 22.9 in (584 mm) Length: 984.25 in (25000 mm) |
| Acceptable tool | Special blade for CAMM-1 series |
| Maximum cutting speed | 19.69 in/s (500 mm/s) (all directions) |
| Maximum cutting media thickness | Up to .04 in (1 mm) |
| Cutting speed | .4 in to 19.69 in/s (10 to 500 mm/sec) (all directions) |
| Blade force | 30 – 350 gf |
| Mechanical resolution | 0.000492 in./step (0.0125 mm/step) |
| Software resolution | 0.000984 in./step (0.025 mm/step) |
| Distance accuracy(1) | Error of less than ±0.2 % of distance traveled, or ±0.1 mm, whichever is greater |
| Repetition accuracy (1)(2) | ±0.1 mm or less |
| Alignment accuracy for printing and cutting when loading printed material (1) (3) | ±1 mm or less for movement distance of 210 mm or less in material-feed direction and movement distance of 170 mm or less in width direction (Excluding effects of printer and/or material) |
| Interface | USB interface (compliant with Universal Serial Bus Specification Revision 2.0 Full Speed, Connecting Multiple Units) |
| Re-plot memory | 2MB |
| Instruction system | CAMM-GL III |
| Power supply | Dedicated AC adapter |
| Input: | AC 100 to 240 V ±10 % 50/60 Hz 1.7 A |
| Output: | DC 24 V, 2.8 A |
| Power consumption | Approx. 30 W (including AC adapter) |
| Acoustic noise level during operation | 70 dB (A) or less (according to ISO 7779) |
| Acoustic noise level during standby | 40 dB (A) or less (according to ISO 7779) |
| Dimensions | 33.5 in (W) × 12.2 (D) × 9.17 (H) With stand 33.5 in (W) X 12.2 (D) X 40.75 (H) |
| Weight | 29.77 lbs. [13.5 kg] With stand 58 lb. [26 kg] |
| Packaging size | 38 (W) x 17.7 (D) x 15.3 (H) in. [975 (W) x 450 (D) x 390 (H) mm] |
| Packaging weight | 39.7 lb. (18 kg) |
| Environment | Temperature: 5 to 40°C (41 to 104°F), humidity: 35 to 80 % (no condensation) |
| Included items | AC adapter, power cord, blade, blade holder, roller base, alignment tool, USB cable, Set Up guide |
1: According to material and cutting conditions as specified by Roland DG Corp. (using the PNS-24 stand, sold separately). 2: Excluding material expansion and contraction. Provided that media length is under 1600 mm. 3: Using Roland DG CutStudio, a laser or inkjet printer having a resolution of 720 dpi or better. Excluding glossy or laminated material. Excluding effects of printing distortion due to printer precision and effects of material expansion, contraction, or warping. Depending on the ink (black) employed by the printer used, correct sensing may not be possible.
Software
| Operating System | Application Software | |
| Roland DG OnSupport | Windows®*7/8/8.1/10 (32/64-bit) | — |
| Roland DG CutStudio | Windows®*7/8/8.1/10 (32/64-bit) | — |
| Roland DG CutStudio Plug-in for Adobe®Illustrator® | Windows®, MAC OS* | Adobe® Illustrator® CC (2014) / CC (2015) / CC (2017) |
| Roland DG CutStudio Plug-in for CorelDRAW® | Windows®* | CorelDRAW® X6/X7/X8/2017 |
*Supported operating system is limited to the version that is supported by the graphic software
Bring the Heat
The GS-24 is perfect for cutting heat-applied materials. It allows you to really heat up your apparel production by personalizing t-shirts, jerseys, caps, jackets, gym bags, and more.
Sign Up For Superiority
Turn heads and increase foot traffic. Quickly and easily create vibrant, eye-catching, unique signage.
Dial Up Your Decals
Utilize the easily selectable half-cut function—so you can create decals ready for individual sale. This feature not only minimizes the need for weeding, but also improves post-production workflow.
Graphics are our Specialty
Looking to build your specialty graphics business? To offer everything from personalized promotional products and accessories, to apparel and packaging on unique substrates? It’s all possible with the highly versatile, high performance, easy-to-use GS-24.
Every Seat is a Window Seat
The GS-24 opens up windows of opportunity! With software like FilmDesign Pro, you can cut any brand of vehicle window tint with immaculate precision.
Clear Paint Protection
Keep your vehicle’s paint pristine. Shield it from flying rocks, debris, shopping carts, and more by using the GS-24 to precisely and easily cut urethane paint protection films.
Bling it on
R-WearStudio, our patented software designed for apparel, makes rhinestone application quick, easy, and right on the money.
